| Image Ref | Part Code | Item Name | Fitted Qty | Price | Order Qty | Stock | |
|---|---|---|---|---|---|---|---|
| 01 | 925668 | CLUTCH ASSY.(STARTING) | 1 | £188.06 | Available in 14-21 days | ||
| 02 | 925818 | C.D.I. | 1 | £211.92 | Available in 14-21 days | ||
| 02-1 | 924452 | Bush, Rubber | 1 | £4.94 | In Stock | ||
| 03 | 924413A | Ignition High Tension Line Assy | 1 | £56.98 | Available in 14-21 days | ||
| 03-1 | GE5139906A | Coil Set, Ignition | 1 | £22.27 | Available in 14-21 days | ||
| 03-2 | 924285 | Spark Plug Attachment | 1 | £8.93 | Available in 14-21 days | ||
| 04 | S70607 | SCREW, SOCKET HEAD M6X20 | 2 | £0.29 | Available in 14-21 days | ||
| 05 | 440564 | Earth Terminal | 1 | £3.07 | Available in 14-21 days | ||
| 06 | 924912B | Flywheel Magneto Assy | 1 | £217.92 | Available in 14-21 days | ||
| 06-1 | D9900033 | Rotor Assy - Before 007559 | 1 | £156.19 | In Stock | ||
| 06-1A | 925870 | Rotor Assy | 1 | £156.19 | Available in 14-21 days | ||
| 06-2 | 924415E | Stator Assy - Before 007559 | 1 | £227.71 | Available in 14-21 days | ||
| 06-2-1 | 925809 | FIXING PLATE | 1 | £3.31 | In Stock | ||
| 06-2-2 | S99616 | BOLT, FLANGE M6X36 | 3 | £1.82 | In Stock | ||
| 06-2A | 924415B | Stator Assy | 1 | £229.63 | In Stock | ||
| 06-2B | 927995A | STATOR ASSY. - Without EPS | 1 | £222.86 | Available in 14-21 days | ||
| 06A | 927992B | Flywheel Magneto Assy | 1 | £217.92 | Available in 14-21 days | ||
| 07 | S70811 | BOLT M8X20 | 6 | £0.96 | In Stock | ||
| 09 | 924937 | No.1 Clamp | 1 | £3.41 | Available in 14-21 days | ||
| 10 | S13502 | SCREW,CROSS RECESSED,PAN HEAD M5X10 | 3 | £0.67 | In Stock | ||
| 11 | 924470E | START MOTOR ASSY. - BEFORE 024082 | 1 | £166.32 | Available in 14-21 days | ||
| 11-1 | P30405 | PIN - BEFORE 024082 | 1 | £2.02 | In Stock | ||
| 11-2 | 925302 | GEAR - BEFORE 024082 | 1 | £27.89 | Available in 14-21 days | ||
| 11-3 | R00201 | SNAP RING, C TYPE - BEFORE 024082 | 1 | £0.86 | In Stock | ||
| 12 | S24607 | BOLT, FLANGE M6X32 - BEFORE 024082 | 2 | £0.62 | Available in 14-21 days | ||
| 13 | 925864 | Gear Sensor Assy | 1 | £46.80 | In Stock | ||
| 13-1 | 924246 | CONTACT PIN, SWITCH, GEAR SELECT | 2 | £2.98 | In Stock | ||
| 13-2 | 925858 | SPRING , SWITCH, GEAR SELECT | 2 | £0.77 | In Stock | ||
| 14 | S79501 | SCREW, SOCKET HEAD M5x16 | 2 | £0.29 | In Stock | ||
| 15 | D9900040 | KEY | 1 | £3.84 | In Stock | ||
| 16 | N10803 | NUT, FLANGE | 1 | £3.46 | In Stock | ||
| 17 | 924282 | NO.2 CLAMP | 1 | £1.01 | Available in 14-21 days |
